75-BSJ-IR 10.66:1/SSE-1/SSE-2/FA/72.00/S
Can't find what you're looking for? Go to the Product Selector
Ball Screw Jack
Inch Worm Gear Ball Screw Jack, Inverted Rotating, Standard, 75 ton Capacity, 10.66:1 Gear Ratio, Travel Nut Position A
**Costs associated with shipping, packaging, import taxes/duty, and surcharges not included.
Max Travel Length
Min: 1.0 in Max: 240.0 in To the nearest .01 in
Jack Configuration
- Improved speed, force, duty cycle, acceleration
- Longer life cycle (low friction)
- Requires less motor power
- Greater positioning accuracy
| Dimension | Value |
|---|---|
| L | 1,828.80 mm (72.000 in) |
| Dimension | Value |
|---|---|
| Unit Of Measure | All length values in: Inches |
| Performance | Value |
|---|---|
| Capacity | 667,233 N / 150,000.00 lbf |
| Torque to Raise 1 lb [0.45 kg] | 0.0027 N·m / 0.0240 in.-lb. |
| Max Input Torque | 413.53 N·m / 3,660.00 in.-lb. |
| Max Input kW/HP | 20.90 kW / 28.00 hp |
| Max Worm Speed Rated Load | 482 rpm |
| Max Capacity at 1750 rpm | 183,836 N / 41,328 lbf |
| Tare Drag Torque | 17.513 N·m / 155.000 in.-lb. |
| Back Drive Holding Torque | 149.140 N·m / 110.000 ft.-lb. |
| Jack Travel Rate at 1750 RPM | 4,445 mm/min / 175 in/min |
