50-BSJ-IR 32:1/SSE-1/SSE-2/FA/72.00/S
Can't find what you're looking for? Go to the Product Selector
Ball Screw Jack
Inch Worm Gear Ball Screw Jack, Inverted Rotating, Standard, 50 ton Capacity, 32:1 Gear Ratio, Travel Nut Position A
**Costs associated with shipping, packaging, import taxes/duty, and surcharges not included.
Max Travel Length
Min: 1.0 in Max: 240.0 in To the nearest .01 in
Jack Configuration
- Improved speed, force, duty cycle, acceleration
- Longer life cycle (low friction)
- Requires less motor power
- Greater positioning accuracy
| Dimension | Value |
|---|---|
| L | 1,828.80 mm (72.000 in) |
| Dimension | Value |
|---|---|
| Unit Of Measure | All length values in: Inches |
| Performance | Value |
|---|---|
| Capacity | 444,822 N / 100,000.00 lbf |
| Torque to Raise 1 lb [0.45 kg] | 0.0016 N·m / 0.0140 in.-lb. |
| Max Input Torque | 157.05 N·m / 1,390.00 in.-lb. |
| Max Input kW/HP | 3.73 kW / 5.00 hp |
| Max Worm Speed Rated Load | 227 rpm |
| Max Capacity at 1750 rpm | 57,622 N / 12,954 lbf |
| Tare Drag Torque | 10.169 N·m / 90.000 in.-lb. |
| Back Drive Holding Torque | 13.558 N·m / 10.000 ft.-lb. |
| Jack Travel Rate at 1750 RPM | 1,372 mm/min / 54 in/min |
