0.5-BSJ-IR 20:1/SSE-1/SSE-2/FA/12.00/S
Can't find what you're looking for? Go to the Product Selector
Ball Screw Jack
Inch Worm Gear Ball Screw Jack, Inverted Rotating, Standard, 1/2 ton Capacity, 20:1 Gear Ratio, Travel Nut Position A
Lead Time:
12 Weeks*
*Lead times may increase with quantity. Displayed lead times (in business days or weeks) do not include transit time.
**Costs associated with shipping, packaging, import taxes/duty, and surcharges not included.
Max Travel Length
Min: 1.0 in Max: 72.0 in To the nearest .01 in
Jack Configuration
- Improved speed, force, duty cycle, acceleration
- Longer life cycle (low friction)
- Requires less motor power
- Greater positioning accuracy
| Dimension | Value |
|---|---|
| L | 304.80 mm (12.000 in) |
| Dimension | Value |
|---|---|
| Unit Of Measure | All length values in: Inches |
| Performance | Value |
|---|---|
| Capacity | 4,448 N / 1,000.00 lbf |
| Torque to Raise 1 lb [0.45 kg] | 0.0005 N·m / 0.0040 in.-lb. |
| Max Input Torque | 0.45 N·m / 4.00 in.-lb. |
| Max Input kW/HP | 0.12 kW / 0.17 hp |
| Max Worm Speed Rated Load | 1,800 rpm |
| Max Capacity at 1750 rpm | 4,448 N / 1,000 lbf |
| Tare Drag Torque | 0.113 N·m / 1.000 in.-lb. |
| Back Drive Holding Torque | 0.339 N·m / 0.250 ft.-lb. |
| Jack Travel Rate at 1750 RPM | 432 mm/min / 17 in/min |
