WH08Z200-00700-02450-AZ1200-84
Can't find what you're looking for? Go to the Product Selector
Lineareinheit, WH80, Riemen Drive, Rad Guide, 0.05 mm Repeatability, 700 mm Nennhubbereich, 2450 mm Overall Length, Doppel-Standardschlitten, 1200 mm between carriages, 200 mm Travel Per Shaft Rev, Welle links, 10 m/s Maximum Linear Speed, Älteres Modell
Lead Time:
4 Weeks *
*Lead times may increase with higher quantities. Lead time displayed in business days.
- In alle Richtungen einbaubar
- Geschwindigkeit bis 10 m/s
- Belt Driven
- Mit Riemenantrieb
| Merkmale | Werte |
|---|---|
| [LA] Schlittenabstand | 1200 mm |
| Hubweg pro Wellenumdrehg. | 200 mm |
| Ltot | 2450 mm |
| Smax (Hub) | 700 mm |
