MJ-20-UR 5:1/SSE-1/SSE-2/FA/12.00/S
Can't find what you're looking for? Go to the Product Selector
Mini Machine Screw Jack
Inch Worm Gear Mini Machine Screw Jack, Upright Rotating, Standard, 5:1 Gear Ratio, Travel Nut Position A
Lead Time:
4 Weeks*
*Lead times may increase with quantity. Displayed lead times (in business days or weeks) do not include transit time.
**Costs associated with shipping, packaging, import taxes/duty, and surcharges not included.
Max Travel Length
Min: 1.0 in Max: 72.0 in To the nearest .01 in
Jack Configuration
- Low noise
- Ideal for vertical loads
- Safe for static loads
- Lower cost
| Dimension | Value |
|---|---|
| L | 304.80 mm (12.000 in) |
| Dimension | Value |
|---|---|
| Unit Of Measure | All length values in: Inches |
| Performance | Value |
|---|---|
| Capacity | 4,448 N / 1,000.00 lbf |
| Torque to Raise 1 lb [0.45 kg] | 0.0021 N·m / 0.0190 in.-lb. |
| Max Input Torque | 2.15 N·m / 19.00 in.-lb. |
| Max Input kW/HP | 0.25 kW / 0.33 hp |
| Max Worm Speed Rated Load | 1,090 rpm |
| Max Capacity at 1750 rpm | 2,807 N / 631 lbf |
| Lift Screw Efficiency | 57% |
| Jack Travel Rate at 1750 RPM | 2,210 mm/min / 87 in/min |
