DA36-20A65M45
Can't find what you're looking for? Go to the Product Selector
Especial - Actuador, LA14, 36 V CC, 2250 N, 450 mm, Sin realimentación, Cable length 165 mm, Connector, 12 mm/s Velocidad de carrera con carga completa
Lead Time:
Contact Factory *
*Lead times may increase with higher quantities. Lead time displayed in business days.
**Costs associated with shipping, packaging, import taxes/duty, and surcharges not included.
- Rugged and robust
- Withstands very harsh environments
- Stainless steel extension tube
- Corrosion free aluminium cover tube
- Trunnion mounting possible
| Unidad | Valor |
|---|---|
| [A] | 666.7 mm |
| [S] | 450 mm |
| Rendimiento | Valor |
|---|---|
| Carga, dinámica | 2250 N |
| Carga, estática máx. | 11350 N |
| Duty Cyle | 25 % |
| Restraining Torque | 0 Nm |
| Velocidad de carrera con carga completa | 12 mm/s |
| Velocidad de carrera sin carga | 15 mm/s |
